Surface604 Rook, 960wh Battery
$2,699.00
The Surface 604 Rook is a comprehensive electric town bike that comes fully-loaded with features including a powerful 500W Bafang motor activated by a smooth accelerating torque sensing system and an upgraded long-range 960wh battery.
The Rook’s incredibly smooth torque sensor knows how hard you’re pedaling down to the microsecond and matches it with proportionate power.
With its easy-going step-thru frame, stylishly integrated lights, rear rack and fenders, the award-winning Surface604 Rook is an excellent all-around electric bike.
Available with Class 2 or Class 3 settings.
The Surface604 Rook Electric Bike is 100% designed and engineered in Canada. These are high-performance electric bicycles with hydro-formed frames, entirely custom designed and constructed for a premium e-bike riding experience.
Featuring a powerful 500W (750 peak) Bafang Geared Hub Brushless Motor and an industry-leading 12mosfet 25A controller, so Surface 604 e-bikes deliver unmatched torque, speed and reliablilty.
But unlike cheaper cadence-sensor driven ebikes that lurch and then suddenly drop out, Surface604 electric bikes feature precision torque-sensors for a smoother and more natural feeling ride.
Whisper Smooth Torque Sensing Pedal Assistance
So long jumpy cadence sensors – an electric bike is only as good as it’s power distribution.
Surface604 electric bikes use a frame-mounted torque sensor system that monitors 104 cadence pulses per revolution and 1,000 torque samples per second.
This hyper-accurate torque-sensing system translates into seamless proportional pedal assistance from a 500 watt continuous / 750 watt peak power Bafang motor that ramps up when you actually need it and then fades off just as seamlessly.
Long-range batteries on all Surface604 bikes at Electric Cyclery.
An exceptional power pack. We think its totally worth the extra cost.
Although Surface 604 bikes are also available with smaller 672wh batteries, we prefer to stock the longer range 960wh batteries for in-store purchases.
- 48V20ah (960wh) 5000mah cell size (Same as in Tesla)
- Samsung Cells 21700, Made in Korea with an external charging USB Plug
- Range up to 65 Miles (105 Kms), Weight: 10.23 LBS (4.65 KG)
RECOMMENDED RIDER HEIGHTS
Small/Medium frame: 5’2”-5’7”
Medium/Large frame: 5’8” – 6’6”
| Size | Medium/Large, 19.5", Small/Medium, 17.5" |
|---|---|
| Color | Black / Gray, White |
| Motor | 500W (Peaks At 750W) Bafang Geared Hub Brushless Motor |
| Battery | 48V 20Ah / 960Wh, Samsung lithium-ion 21700 cells |
| Motor Control | Thumb Throttle, Torque Pedal Assist |
| Range | Up to 65 miles |
| Forks | SR Suntour XCM HLO |
| Derailleur | Shimano Alivio 9 speed |
| Brakes | Tektro Auriga hydraulic disc brakes – Front and Rear |
| Frame | Tapered Headtube, Reinforced Battery Mounts, Internal Cable Routing |
| Tires | KENDA KWICK 27.5" X 2.4" with Reflective Trim |
| Wheel size | 27.5 inch |
| Charging Time | 4 hours |
| Handlebar | 30mm Rise With 15° Backsweep and 700mm Wide |
| Lights | High-powered BÜCHEL front and rear lights |
| Grips | PU Leather Wrapped, Full Length 145mm |
| Weight | 61 lbs. |
| Manufacturer | Surface 604 |
| Warranty | One year on components |
